BDQ235B BDSS400TS hot rolled steel chequered coils
we provide various carbon steel and stainless steel material chequered coils
can support customization
OEM/ODM
- Overview
- Recommended Products
Product Induction
Our BDQ235B and BDSS400TS patterned rolled plates are specifically designed to cater to a wide range of applications, each with its unique requirements.
BDQ235B Plate:
- Material: Q235B Carbon Structural Steel
- Yield Strength: ≥235MPa
- Applications: Ideal for general building structures, industrial platforms, and stair treads, especially in cost-sensitive environments.
- Features: Offers a balance of strength and affordability, making it suitable for construction projects with average strength needs.
BDSS400TS Plate:
- Material: SS400 Structural Steel with Vanadium
- Tensile Strength: ≥400MPa
- Applications: Perfect for high-end uses such as new energy vehicles and intelligent garages where lightweight, high strength, and excellent formability are critical.
- Features: Enhanced strength and toughness due to the incorporation of vanadium, making it suitable for demanding applications.
Both plates are meticulously crafted to ensure reliability, performance, and durability in their respective uses.
Specification
Chequered Plate Coils Stock: MOQ: One Piece,Cut to Length Cut to Size
| 1.8*1500 | 2.75*1250 | 3.0*1250 | 4.75*1250 | 5.75*1500 |
| 2.5*1250 | 2.75*1500 | 3.75*1250 | 4.75*1500 | 7.5*1500 |
| 2.5*1500 | 3.0*1500 | 3.75*1500 | 5.5*1500 |
| Product Name | BDQ235B BDSS400TS hot rolled steel chequered coils |
| Technique | Hot Rolled |
| Grade | BDQ235B BDSS400TS |
| Shape | Diamond-shaped, lentil-shaped, round-shaped |
| Thickness |
BDQ235B:2.0mm - 9.0mm BDSS400TS:1.2mm - 8mm |
| Width | 600mm - 1800mm |
| Length | 2000mm - 12000mm |
| Application |
BDQ235B: Suitable for cost-sensitive applications with moderate strength requirements, such as general building structures, standard industrial platforms, and stair treads. BDSS400TS: Suitable for high-end applications with stringent requirements for lightweight construction, high strength, and formability, such as new energy vehicles and high-end smart garages. |
chemical composition
| Grade | C % | Si % | Mn % | P % | S % |
| BDQ235B | 0.14-0.22 | ≤0.30 | 0.30-0.65 | ≤0.045 | ≤0.050 |
| BDSS400TS | 0.16-0.20 | 0.15-0.35 | 0.90-1.60 | ≤0.040 | ≤0.040 |
mechanical properties
| Grade | tensile strength（MPa） | yield strength（MPa） | Elongation% |
| BDQ235B | 375-500 MPa | ≥235 MPa | ≥26% |
| BDSS400TS | ≥400-510 MPa | ≥245-400 MPa | ≥21-26% |
Manufacturing Process for Hot-Rolled Patterned Steel Plates
1. Raw Material Preparation: Select the appropriate grade; thickness is typically 150–250 mm. Inspect the slab surface quality and remove any defects.
2. Heating: Heat to a temperature of ≥1250°C to reduce deformation resistance and facilitate subsequent rolling. The heating time is determined based on the slab thickness to ensure uniform core temperature.
3. High-Pressure Water Descaling: Use high-pressure water jets to remove the iron oxide scale formed on the slab surface after heating.
4. Rough Rolling Stage: Vertical roughing rolls (to control width) + horizontal roughing rolls (to control thickness).
5. Descaling before finishing: High-pressure water is used again to remove secondary iron oxide scale.
6. Finishing: During rolling at the final stand, the upper work roll applies downward pressure, imprinting a lentil-shaped groove on the upper surface of the workpiece to form a raised pattern.
7. Laminar cooling: The cooling rate is controlled to achieve the desired microstructure and properties.
8. Finishing operations: Cooling, leveling, cross-cutting, inspection, and storage.
FAQ
Q: What is the difference between Q235B and SS400TS?
A: Q235B is carbon structural steel, while SS400 is vanadium-containing microalloyed steel.
Q: Does the thickness of checkered plate refer to the base plate thickness or the total thickness including the checkered pattern?
A: In industry standards, the thickness of checkered plate refers to the base plate thickness (excluding the checkered pattern). For example, a 3mm checkered plate refers to a base plate thickness of 3mm, with the checkered pattern height calculated separately (typically 0.5–2.5mm).
Q: What are the common thickness specifications? What is the theoretical weight?
A: Standard thickness specifications (GB/T 3277-2017): 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0, 7.0, 8.0 mm.
Q: What is the minimum order quantity? What is the lead time?
A: The minimum order quantity is 1 ton. Items in stock are shipped within 7 days; special sizes require new production.
