1000mm 1200mm PPGI Color Coated Prepainted Galvanized Steel Coil

Product Induction

High-quality pre-painted galvanized steel coils seamlessly combine a corrosion-resistant galvanized substrate with a high-performance architectural-grade coating. Available in two standard widths—1,000 mm and 1,200 mm—to optimize global logistics efficiency and downstream processing productivity. The factory pre-coating process ensures exceptional color consistency and durability. The product is ready for immediate processing, eliminating the need for on-site painting, thereby avoiding construction delays and environmental compliance concerns.

Standard Width Specifications

• Optimal for Asian market standards and container loading efficiency
• Ideal slitting into two 500mm strips or four 250mm sections
• Perfect match for roofing panel profiles with 850-900mm effective coverage
• Maximum coil weight efficiency in 20ft and 40ft container configurations

• Versatile intermediate format compatible with European and American equipment
• Efficient blanking layout for standard 600mm or 400mm components
• Optimal for standing seam roofing with 1100-1150mm coverage after profiling
• Reduces scrap generation for medium-format panel production

• Standard stock: 0.30mm – 1.20mm
• Popular construction gauges: 0.40mm, 0.50mm, 0.60mm, 0.80mm
• Heavy gauge options: 1.00mm, 1.20mm (special order)
• Thickness tolerance: ±0.02mm for gauges below 0.60mm, ±0.03mm for 0.60mm and above

Color Range & Finish Options

• RAL Classic: 200+ colors maintained in regular production
• Popular architectural colors: Traffic White RAL 9016, Pure White RAL 9010, Slate Grey RAL 7015, Anthracite RAL 7016, Brick Red RAL 8004, Moss Green RAL 6005
• Metallic finishes: Silver, champagne, copper, and custom metallic effects
• Special textures: Wrinkle, hammer tone, and embossed finishes available

• Physical sample matching service
• Spectrophotometer color verification (Delta E ≤1.0)
• Minimum 25 tons per custom color for mill production
• Color retention archives maintained for 3 years for repeat orders

• High gloss: 80-90 GU (gloss units) at 60°
• Semi-gloss: 40-60 GU at 60°
• Low gloss: 15-30 GU at 60°
• Matte: 5-10 GU at 60°

Processing Capabilities

• 1000mm coil: Slit to 50-500mm widths
• 1200mm coil: Slit to 50-600mm widths
• Tolerance: ±0.3mm width, maximum 0.1mm burr height
• Edge conditioning: Deburring and chamfering available

• Sheet length: 500mm – 4000mm standard
• Length tolerance: ±1.0mm
• Diagonal tolerance: Maximum 2mm per 2000mm width
• Automatic stacking with paper interleaving and palletizing

• Technical consultation for roll-forming die design
• Lubrication recommendations for coating protection during forming
• Minimum bend radius guidelines by paint system and thickness

• Protective film lamination (50-80 micron PE film)
• Embossing: Stucco, leather grain, or custom patterns
• Perforation: Round, square, or decorative patterns
• Curving: Crimp-curved sheets for architectural applications

FAQ

Q: What thicknesses are available for products in these widths?
Standard stock: 0.30 mm to 1.20 mm. Primary applications in the construction sector are as follows:
0.40–0.50 mm: Lightweight roofing and wall cladding
0.60–0.80 mm: Industrial roofing, structural panels
1.00 mm+: Heavy-duty applications, insulation panels
Custom thicknesses outside this range can be ordered directly from the factory, with a lead time of 6–8 weeks.

Q: What galvanized coating thicknesses do you offer? Which one should I choose?

A: Z40, Z80, Z120, Z180, Z275

Q: Can you match my corporate colors or specific RAL color codes?

A: Of course. We stock over 200 classic RAL colors and offer custom color options.
