Tianjin Emerson EN10025 S500Q S500QL S500QL1 High Strength Custom Steel Plate Cut to Length
We can supply common Carbon Steel,Checkered Plate,Cold Rolled base Material,Low Alloy High-Strength Steel,Tool Steel and other automotive steel, construction machinery steel, container steel, weather resistant steel.
- Overview
- Recommended Products
Product Induction
EN10025 S500Q S500QL S500QL1 high-strength steel plates represent the premium grade compliant with EN 10025-6. This standard specifies the technical delivery conditions for flat products of high-yield strength structural steel in the quenched and tempered (Q+T) condition. The S500 series belongs to the medium-to-high strength structural steel grades, achieving a minimum yield strength of 500 MPa.
The primary distinction among these three grades lies in their differing low-temperature impact test temperatures. Designed for demanding environments and high-strength durability requirements, this series of steel plates offers exceptional mechanical properties and excellent weldability, making it widely applicable in industries such as construction, mining, and machinery manufacturing.
Specification
chemical composition:
| Grade | C | Si | Mn | N | Cr | Cu | Mo |
| EN10025 S500Q | ≤0.20% | ≤0.80% | ≤1.70% | ≤0.015% | ≤1.50% | ≤0.50% | ≤0.70% |
mechanical properties:
| Grade | tensile strength（MPa） | yield strength（MPa） | Elongation% |
| EN10025 S500Q | 540-770 | ≥440 MPa | 17% |
steel sheet plate specification
| Product Name | Tianjin Emerson EN10025 S500Q S500QL S500QL1 High Strength Custom Steel Plate Cut to Length |
| Category | High Strength Plate |
| Grade | S500Q S500QL S500QL1 |
| Material Stocking |
Common Carbon Steel: A36,A36M,JJ195L,11235L,JJ235M,SAPH400-C,SS40-ZJ,A36-001,SS40-FST,Q235C Q235D Checkered Plate:BDQ235B,BDSS400TS,BDQ235B-Z01 Cold Rolled base Material:Q195,SPHC,SPHD,DD11,DD12,SAE1006/1008/1010/1012/1016/1018 Low Alloy High-Strength Steel:Q345B,Q355B-ZH,Gr50,S235JR,Q355C,S275JR,BDQ355B,S355J2 Tool Steel:20#,35#,40#,S45C and other automotive steel, construction machinery steel, container steel, weather resistant steel. |
| Thickness | steel sheet:0.4-4mm,medium thick steel plate:4.5-25mm,25-100mm |
| Width | steel sheet:500-2500mm,medium thick steel plate:1000-3000mm |
| Surface Treatment | Pickled & Oiled,Hot-Dip Galvanizing,PPGI,Painting/Powder Coated |
| Delivery | Q+T |
Stock
MOQ: One Piece to Cut to Length Cut to Size
| 2.3*1500 | 2.5*1500 | 3.0*1500 | 3.5*1500 | 3.75*1500 | 4.5*1500 |
| 4.75*1500 | 5.5*1500 | 5.75*1500 | 6.0*1500 | 7.5*1500 | 7.75*1500 |
| 8.0*1500 | 9.75*1500 | 10.0*1500 | 11.5*1500 | 11.75*1500 | 13.5*1500 |
| 13.75*1500 | 15.75*1500 | 2.75*1500 | 4*1500 | 9.5*1500 | 4.75*1800 |
| 7.75*1800 | 9.75*1800 | 11.75*1800 | 15.75*1800 |
Selection Suggestions
| Usage environment | Recommended material | Applicable temperature range |
| Normal temperature or general low temperature environment | S500Q | ≥-20°C |
| Cold regions or low temperature conditions | S500QL | ≥-40°C |
| Extreme cold environment or ultra-low temperature application | S500QL1 | ≥-60°C |
Application Field
Construction machinery: hydraulic support, crane telescopic arm, crane boom, excavator support arm
Mining machinery: mining equipment, conveyor structural components
Coal mining machinery: key load-bearing components such as hydraulic supports
Bridge construction: load-bearing structures and connecting components
Heavy vehicles: frame and chassis structure
Port machinery: large lifting equipment
Ship and Ocean Engineering: Ship Structure, Ocean Platforms
FAQ
Q: What is the difference between S500Q, S500QL, and S500QL1?
A: All three grades share the same base mechanical properties with 500 MPa minimum yield strength. The key difference lies in impact toughness at different temperatures.
Q: What are the equivalent steel grades in other standards?
A:ASTM/ASME: A514 Grade F / A517 Grade F (approximate)
DIN: TStE 500 V
SEW: FeE 500 V KT
GB/T: Q500E (Chinese standard)
ISO: E500CCU/E500DDU
Q: What is the delivery condition of these plates?
A:Thickness: 8-200mm
Width: 1,000-4,000mm
Length: Up to 18,000mm
Custom dimensions available upon request
Q: Which grade should I choose for my application?
A:S500Q: General structural use, temperate climates, standard loading conditions
S500QL: Cold climates (down to -40°C), dynamic loading, critical safety structures
S500QL1: Arctic conditions (down to -60°C), extreme low temperature applications, cryogenic equipment
